GM IGNITION COIL 4P CONNECTOR KIT

Item Number

· DE-ICP-GT150-4P

· Delphi Item No.: 15413116, 15439568

Item Including

· Connector Housing ×1

· Lock Part/TPA ×1

· Female Terminal Contact Pin ×4

· Wire Seal/Cavity Plug Seal ×4

Product Parameter

· Delphi 4P Female Connector (Plug Housing)

· Connector Series: GT150 Sealed

· Mating Pin Diameter: 1.5 mm [ .059 in ]

· Current Rating: 15 Amps all contacts

· Wire Range: 18-22 AWG (0.82-0.32mm sq)

· L: 31.7mm W: 23.7mm H: 17.6mm

· Unit Weight: 9.2g / 0.0203lb

Main Application

· D581 (12558693) LS9 LQ9 Truck Coil

· D585 (10457730 AC Delco) (19005218 Delphi) Yukon/Truck Coil

· D513A (12570616) LS2/LS7 - 1st design Coil

· D514A (12573190) LS2/LS7 - 2nd design Coil

· MSD (PN# 82478) LS2/LS7 Multiple Spark Coil

· GM (12611424) 2005 + LS3 LSA Coil
